Magnetic Effects of Electric Current

Cheatsheet Content

Magnetic Field and Field Lines Magnet: Any substance that attracts iron or iron-like substances. Magnetic Field: The region surrounding a magnet, in which the force of the magnet can be detected. It is a vector quantity, having both magnitude and direction. Magnetic Field Lines (Magnetic Lines of Force): Imaginary lines representing the magnetic field. Emerge from the North pole and merge into the South pole (outside the magnet). Inside the magnet, the direction of field lines is from its South pole to its North pole. Magnetic field lines are closed curves. No two magnetic field lines are found to intersect each other. If they did, it would mean that at the point of intersection, the compass needle would point in two directions, which is not possible. The relative strength of the magnetic field is shown by the degree of closeness of the field lines. Stronger field means closer lines. Magnetic Field due to Current-Carrying Conductors 1. Magnetic Field due to a Straight Current-Carrying Conductor The magnetic field lines are concentric circles centred at the conductor. Direction: Determined by Maxwell's Right-Hand Thumb Rule (also called Right-Hand Rule). If you hold the current-carrying straight conductor in your right hand such that your thumb points towards the direction of current, then your fingers will wrap around the conductor in the direction of the magnetic field lines. Strength: Directly proportional to the current ($I$) and inversely proportional to the distance ($r$) from the conductor. 2. Magnetic Field due to a Current through a Circular Loop At every point on the circular loop, the concentric circles representing the magnetic field around it would become larger and larger as we move away from the wire. By the time we reach the centre of the loop, the arcs of these big circles would appear as straight lines. The magnetic field lines are almost straight at the centre of the circular loop. Direction: Can be determined by the Right-Hand Thumb Rule for each segment of the loop. If current is clockwise, North pole is formed on the side from which current looks clockwise (South pole on the other side). If current is anti-clockwise, South pole is formed on the side from which current looks anti-clockwise (North pole on the other side). Strength: Directly proportional to the current ($I$) and the number of turns ($N$) in the loop, and inversely proportional to its radius ($R$). 3. Magnetic Field due to a Current in a Solenoid A coil of many circular turns of insulated copper wire wrapped closely in the shape of a cylinder is called a solenoid. The magnetic field inside a long straight solenoid is uniform (same at all points) and strong. The field lines inside the solenoid are parallel straight lines. The pattern of the magnetic field lines of a solenoid is similar to that of a bar magnet. One end of the solenoid acts as a North pole, and the other end as a South pole. Direction: The polarity (North/South) can be determined by the clock rule or using the Right-Hand Thumb Rule (if curled fingers point in current direction, thumb points to North pole). Strength: Directly proportional to the current ($I$) and the number of turns per unit length ($n$). Electromagnet A strong magnet made by placing a soft iron core inside a current-carrying solenoid. The magnetism is temporary and exists only as long as current flows. Factors affecting strength: Magnitude of current. Number of turns in the coil. Nature of the core material (soft iron enhances magnetism). Applications: Electric bells, loudspeakers, telephone diaphragms, large cranes for lifting heavy iron pieces. Force on a Current-Carrying Conductor in a Magnetic Field A current-carrying conductor, when placed in a magnetic field, experiences a force. The direction of the force is perpendicular to both the direction of current and the direction of the magnetic field. The magnitude of the force is maximum when the direction of current is perpendicular to the direction of the magnetic field. The force is zero when the conductor is placed parallel to the magnetic field. Direction of Force: Fleming's Left-Hand Rule: Stretch the thumb, forefinger, and middle finger of your left hand such that they are mutually perpendicular. If the forefinger points in the direction of the magnetic field and the middle finger points in the direction of current, then the thumb will point in the direction of motion or the force acting on the conductor. Applications: Electric motor. Electric Motor A device that converts electrical energy into mechanical energy. Principle: Based on the principle that when a current-carrying conductor is placed in a magnetic field, it experiences a force. Construction: Consists of a rectangular coil (armature) of insulated copper wire, a strong field magnet, a split ring commutator, and brushes. Armature: The coil (e.g., ABCD) which rotates. Field Magnets: Provide the magnetic field. Split Ring Commutator: Two halves of a metallic ring (P and Q) which reverse the direction of current in the coil every half rotation, ensuring that the force on the sides of the coil always acts in a direction that sustains the rotation. Brushes: Carbon brushes (X and Y) make contact with the commutator and supply current to the coil from the battery. Working: Current flows from the battery through brush X, through the coil ABCD, and back to the battery through brush Y. Applying Fleming's Left-Hand Rule to sides AB and CD, forces act in opposite directions, causing the coil to rotate. The commutator reverses current direction in the coil every half turn, allowing continuous rotation in the same direction. Electromagnetic Induction The phenomenon of producing induced electric current in a closed circuit by changing the magnetic field passing through it. Ways to induce current: Relative motion between a coil and a magnet. Changing the current in a nearby primary coil, which in turn changes its magnetic field. Induced Current: The current produced due to electromagnetic induction. Direction of Induced Current: Fleming's Right-Hand Rule: Stretch the thumb, forefinger, and middle finger of your right hand such that they are mutually perpendicular. If the forefinger points in the direction of the magnetic field and the thumb points in the direction of motion of the conductor, then the middle finger will show the direction of induced current. Applications: Electric generator. Electric Generator A device that converts mechanical energy into electrical energy. Principle: Based on the principle of electromagnetic induction. Construction: Consists of a rotating rectangular coil (armature) placed between the two poles of a magnet, two slip rings (for AC) or a split ring commutator (for DC), and two brushes. Working: When the coil is rotated in the magnetic field, the magnetic flux linked with it changes, inducing an electromotive force (e.m.f.) and hence an electric current in the coil. Alternating Current (AC) Generator: Uses two slip rings (R1 and R2) connected to the ends of the coil. The current produced reverses direction periodically (typically every half rotation). Direct Current (DC) Generator: Uses a split-ring type commutator. The commutator ensures that the current flowing out into the external circuit is always in the same direction. Domestic Electric Circuits Live Wire (Positive, Red insulation): Carries the current from the power station. At high potential (e.g., 220V). Neutral Wire (Negative, Black insulation): Completes the circuit, usually at zero potential. Earth Wire (Green insulation): Connected to a metal plate buried in the earth. Provides a safety measure, especially for appliances with metallic bodies. It ensures that any leakage current from the appliance body flows to the earth, preventing electric shock. Fuse: A safety device that protects electrical circuits and appliances from damage due to short-circuiting and overloading. It consists of a piece of wire made of a material with a low melting point (e.g., alloy of lead and tin). When current exceeds the fuse rating, it melts and breaks the circuit. Short Circuiting: Occurs when the live wire and the neutral wire come into direct contact. This causes the resistance of the circuit to become very low, and a very large current flows, potentially causing sparks, fire, or damage. Overloading: Occurs when too many electrical appliances are connected to a single socket or when the current drawn by appliances exceeds the permissible limit of the circuit. This leads to excessive heating of wires, which can cause fire.
