Rectangular steel bar

Rectangular steel bar

Mechanical Engineering

Rectangular steel bar

A long straight solid steel bar shown as a prismatic beam-like member with a rectangular cross section. It is metallic gray with a simple machined finish, flat faces, sharp corners, and parallel edges. The bar has a wide face with much smaller thickness, maintaining uniform width and thickness along its entire length.
