Spur gear perspective

A single cylindrical external spur gear shown in slight perspective or three-quarter view, rendered in metallic steel gray with a precise machined finish. The gear has flat side faces, a thick rim or uniform body thickness, a centered circular bore, and optionally a simple hub with solid web. Straight teeth are evenly spaced around the outer rim, cut parallel to the axis with no helix angle, and shown with crisp full-depth involute profiles. The angled view reveals both the circular face and the depth of the toothed wheel, emphasizing its simple industrial machine-element form.
