Flat belt

A generic flat power-transmission belt shown in isolation as either a long flexible strip or a continuous loop, wider and flatter than a V-belt, with a thin uniform rectangular cross section. It has flat parallel top and bottom faces, straight clean side edges with a subtly rounded edge profile, uniform width and thickness throughout, and smooth plain surfaces with no teeth or ribs. The material appears as dark gray, black, or dark brown rubber, rubberized leather, elastomer, or fabric-reinforced polymer with a slightly matte industrial finish. The belt may be gently curved to suggest flexibility.
