Worm gear set

Worm gear set

Mechanical Engineering

Worm gear set

A complete worm gear set showing a cylindrical screw-like worm meshing at right angles with a circular worm wheel. The worm is metallic silver-gray with deep continuous helical threads, while the mating wheel is a thick machined disk with a central hub and curved, slightly concave teeth shaped to match the worm thread. The wheel is often bronze or gold-toned, though both components may also appear metallic gray, and the arrangement clearly shows the perpendicular engagement between the two parts.

Edit this icon in GPAI Canvas — mix it with 80,000+ STEM assets and AI editing tools to ship publication-ready figures in minutes

Format

PNG

License
