Brake disc with pads

A generic mechanical disc brake assembly shown in a simplified engineering style, featuring a circular metallic gray rotor or brake disc with a clearly defined central mounting hub and central opening. A stationary braking element presses against the rotating disc, shown as one or two opposing rectangular brake pads with darker friction lining surfaces. The image clearly distinguishes the rotating disk from the stationary friction-applying member, with robust machined or cast metal surfaces, compact industrial proportions, and a dark friction contact band at the interface.
