Fatigue fracture surface

$Fatigue fracture surface$

Mechanical Engineering

Fatigue fracture surface

Broken end of a metal bar or component shown as a roughly circular to irregular fracture cross section in dull silvery-gray steel. Most of the fracture face is relatively smooth and flat, with concentric beach-mark bands radiating from one edge across a semicircular crack-growth region. On the opposite side, a smaller final overload fracture region appears rough, jagged, and more irregular in texture, contrasting with the smoother fatigue area.
