Helical compression spring squared end

Helical compression spring squared end

Mechanical Engineering

Helical compression spring squared end

Cylindrical helical compression spring made of metallic steel-gray round wire, with uniform coil diameter and closely wound body coils. The terminal turns are closed down so the last turn meets and touches the adjacent coil tangentially, reducing the helix angle to nearly zero at each end and creating flattened, squared seating ends. The top and bottom ends sit level with a planar, finished appearance compared with open-ended springs.

Edit this icon in GPAI Canvas — mix it with 80,000+ STEM assets and AI editing tools to ship publication-ready figures in minutes

Format

PNG

License
