Fatigue crack

Fatigue crack

Mechanical Engineering

Fatigue crack

A generic fatigue crack in metal shown as a thin dark gray to black slit initiating at a free surface, edge, or notch and extending inward through a light to medium metallic gray body. The crack appears narrow, with a very small opening that is slightly wider at the surface and tapers to a sharp pointed crack tip deeper in the material. Edges are sharp, the surrounding material is smooth metallic gray, while remaining overall a slender surface-initiated fissure.

Edit this icon in GPAI Canvas — mix it with 80,000+ STEM assets and AI editing tools to ship publication-ready figures in minutes

Format

PNG

License
