Fixed support

Mechanical Engineering

Fixed support

A rigid built-in beam support shown in standard engineering statics style as a thick vertical wall or rectangular block in dark gray, often with diagonal hatch marks indicating a solid immovable boundary. The support has a flat boundary face, and the end of the beam or member is embedded flush into it, disappearing into the support face to indicate a fixed constraint with no movement or rotation.

Edit this icon in GPAI Canvas — mix it with 80,000+ STEM assets and AI editing tools to ship publication-ready figures in minutes

Format

PNG

License
