Datum feature surface

Datum feature surface

Mechanical Engineering

Datum feature surface

A flat machined datum feature surface depicted as a rectangular metallic gray plane with a precise engineered appearance, while still representing real physical surface imperfection through slight waviness, tiny hills and valleys, and a machined finish. The surface has sharp edges and reads as the functional face used to establish a datum.
