Phasor diagram circular reference

Phasor diagram circular reference

Physics

Phasor diagram circular reference

A circular reference phasor diagram with a central origin and a thin circle surrounding it, suggesting rotational motion or AC phase reference. One horizontal reference axis is present, with one or more arrowed vectors radiating outward from the origin at different angles. The style is clean textbook line art with minimal axes, simple arrowheads, and a schematic appearance appropriate for rotating or wave phasors.
