Solenoid

A long cylindrical solenoid made of many tightly wound, evenly spaced helical turns of wire wrapped around an invisible or lightly indicated straight central axis, forming an elongated hollow tube much longer than its diameter. Shown in side view or slight perspective with a regular spring-like electromagnetic appearance, uniform diameter, open ends visible, and the helical winding pattern clearly defined along its length. Straight wire leads may extend from the ends to emphasize it as an electrical component.
