Amplifier subcircuit with input and output loading

Amplifier subcircuit with input and output loading

Electronics

Amplifier subcircuit with input and output loading

Textbook-style black-line schematic subcircuit of a basic amplifier stage with explicit surrounding resistive elements. On the left, the input connects through a series input resistor, with source resistance and feedback-network input resistance indicated at the input side. On the right, the amplifier output is connected to output loading elements including a load resistance and an output conductance representation. The overall appearance is a clean reusable circuit fragment for analysis.
