N channel enhancement mosfet cross section

N channel enhancement mosfet cross section

Electronics

N channel enhancement mosfet cross section

Cross-sectional view of an n-channel enhancement MOSFET showing a p-type substrate with two heavily doped n+ regions forming the source and drain on either side of the channel area. A thin gate oxide layer lies above the channel region, with a single gate electrode positioned on top. The device layout is symmetrical, using typical semiconductor diagram colors such as a light gray substrate, darker doped source and drain regions, and a gray gate structure.
