Resistor symbol

Resistor symbol

Electronics

Resistor symbol

Clean schematic resistor symbol in zigzag style, suitable for use as a pull-up element. The resistor is shown with simple straight terminal leads on both ends, typically drawn vertically with the top lead connected toward a supply voltage and the bottom lead toward a signal node. Black line-art schematic appearance.
