Frequency response low pass plot

Frequency response low pass plot

Electronics

Frequency response low pass plot

A simple Bode magnitude plot on white background with horizontal axis labeled frequency on a logarithmic scale and vertical axis labeled gain in dB. The curve is flat at low frequency, drops by 3 dB at a marked corner frequency fH, then slopes downward at approximately -20 dB per decade. Clean textbook graph style with black axes and a single smooth response curve.
