Voltage amplifier

Generic 2D schematic symbol for a voltage amplifier shown as a simple rectangular gain block with clean black outline and balanced proportions. Place the signal input terminal on the left and the signal output terminal on the right; the block may use single-ended terminals or terminal pairs, and may optionally include a lower common reference lead. Include minimal gain labeling on the face such as Av, Avo, A, V/V, or a plus sign with the Greek letter mu. Small plus and minus polarity marks may appear at the input and output. Use neat black circuit-diagram line art with a plain, light gray, or white fill, and no surrounding circuit elements.
