Circuit node

Circuit node

Electronics

Circuit node

A small solid black circular junction dot used in circuit schematics to indicate an electrical connection point where wires meet or join. The symbol is a simple filled round dot, typically centered at the junction of intersecting conductors, with short straight wire stubs or line leads extending outward from two, three, or four sides. Rendered as a crisp, minimal isolated electronics diagram element.
