Load resistor rl

Load resistor rl

Electronics

Load resistor rl

Standard 2D schematic load resistor labeled RL or R_L, drawn in simple black line art as a conventional resistor symbol with two terminal leads. The resistor may appear in the common zigzag style or rectangular IEC style, with clean crisp lines and a small label area beside it. It can be shown horizontally with straight leads on both sides or as a minimal vertical zigzag variant, but remains an isolated circuit-symbol representation of an external load element for amplifier or coupling diagrams.
