Output voltage waveform falling

Output voltage waveform falling

Electronics

Output voltage waveform falling

Black timing waveform on simple axes showing output voltage falling from a high level near VDD to a low level near 0 over time. The trace includes a flat high plateau, a downward transition to the low state, and a flat low plateau, presented in a minimal line style. The falling edge may be shown as a straight ramp rather than an ideal instantaneous drop.
