1. Introduction to Foundations A foundation is the lowest part of a structure, transferring the load from the superstructure to the underlying soil or rock. Its primary purpose is to safely and uniformly distribute the building's weight, prevent settlement, and provide stability against various forces. 2. Types of Foundations 2.1 Shallow Foundations These foundations transfer loads to a stratum at a shallow depth, typically within a few meters of the ground surface. They are suitable when the upper soil layers have sufficient bearing capacity. Spread Footings: Individual footings under columns or walls. Isolated Footing: Supports a single column. Wall Footing: Supports a load-bearing wall. Combined Footing: Supports two or more columns when they are closely spaced or near property lines. Mat or Raft Foundation: A large slab covering the entire area beneath a structure, supporting all columns and walls. Used when soil bearing capacity is low or when individual footings would cover more than 50% of the area. Strap or Cantilever Footing: Two or more isolated footings connected by a structural strap beam. Used when an exterior column footing cannot be centered due to property lines. 2.2 Deep Foundations These foundations transfer loads to a deeper, stronger soil or rock stratum when the shallow soil layers are weak or compressible. They are generally more expensive and complex to construct. Pile Foundations: Long, slender members driven or cast into the ground. End-Bearing Piles: Transfer load primarily through their tip to a hard stratum. Friction Piles: Transfer load through skin friction along their shaft with the surrounding soil. Compaction Piles: Used to compact loose granular soils, increasing their bearing capacity. Pier Foundations: Larger diameter cylindrical concrete columns, constructed by excavating a shaft and filling it with concrete. Similar to large-diameter bored piles. Caisson Foundations (Drilled Shafts): Large, watertight retaining structures sunk into the ground to provide access to the seabed for construction. Often used for bridge foundations. 3. Factors Influencing Foundation Choice Soil Bearing Capacity: The maximum load per unit area that the soil can support. Low capacity $\Rightarrow$ Deep or Mat Foundation. High capacity $\Rightarrow$ Shallow Foundation. Type of Superstructure and Loads: Heavy loads require stronger foundations. Groundwater Table: High water table can affect excavation and material choice. Settlement Criteria: Allowable vertical movement of the structure. Economy and Construction Time: Cost-effectiveness and project schedule. Local Building Codes and Regulations. Environmental Factors: Seismic activity, expansive soils. 4. Foundation Formation Process (General Steps) 4.1 Site Investigation and Soil Testing Geotechnical Survey: Boreholes, trial pits to determine soil profile, water table, and soil properties. Laboratory Tests: Shear strength, compressibility, permeability, bearing capacity tests ($q_{ult}$). Reporting: Geotechnical report guides foundation design. 4.2 Design of Foundation Based on structural loads, soil properties, and design codes. Calculations for size, depth, and reinforcement (for concrete foundations). Consideration of differential settlement. 4.3 Site Preparation Clearing and Grubbing: Removal of vegetation, debris. Excavation: Digging to the required depth for footings or basements. Dewatering: Pumping out groundwater if the water table is high to keep excavation dry. Leveling and Compaction: Preparing a stable base for the foundation. 4.4 Construction of Foundations Formwork: Erecting temporary molds for concrete footings or walls. Reinforcement (Rebar): Placing steel bars as per design to resist tensile forces. Concrete Pouring: Placing and compacting concrete into the formwork. Curing: Maintaining moisture and temperature for concrete to gain strength. Backfilling: Filling excavated areas around the foundation with suitable material and compacting it. Pile Driving/Boring (for Deep Foundations): Driven Piles: Piles hammered into the ground. Bored Piles/Piers: Holes drilled, then reinforced and filled with concrete. 5. Common Foundation Problems Differential Settlement: Uneven sinking of different parts of the foundation, leading to cracks in the superstructure. Bearing Capacity Failure: Soil beneath the foundation cannot support the applied load, causing collapse or severe settlement. Frost Heave: Uplift of soil due to freezing of water in the ground, common in cold climates. Expansive Soils: Soils that swell when wet and shrink when dry, causing movement. Groundwater Infiltration: Water entering basements or crawl spaces, causing damage. 6. Foundation Inspection and Quality Control Regular inspection during excavation, rebar placement, and concrete pouring. Concrete strength tests (e.g., cube tests). Verification of dimensions and levels. Compaction tests for backfill.
